Name: JMZ-TK1-40A Customizable Cylindrical Friction Damping Vibration Isolator with Mounting Installation for Energy & Mining
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-TK1-40A
Availability: InStock

À la maison > produits > Isolateur à ressort >

JMZ-TK1-40A Customizable Cylindrical Friction Damping Vibration Isolator with Mounting Installation for Energy & Mining

Customizable Friction Damping Vibration Isolator

Cylindrical Spring Isolator

Mounting Installation Vibration Isolator

Lieu d'origine:

CHINE

Nom de marque:

Hoan

Numéro de modèle:

JMZ-TK1-40A

Nous contacter

Demandez un devis

JMZ-TK1-40A Customizable Cylindrical Friction Damping Vibration Isolator with Mounting Installation for Energy & Mining

Détails du produit

Matériel:

Acier à ressorts

Port:

Xi'an ou spécifié

Plage de température:

-40 ° F à 180 ° F

Couleur:

Argent

Industries applicables:

Énergie et exploitation minière

Garantie:

1 an

Température de fonctionnement:

-40 ° C à 100 ° C

Résilience:

Haut

Absorption des chocs:

Excellent

Durabilité:

Longue durée

Usage:

Isoler les vibrations

Méthode d'installation:

Montage

Personnalisation:

Disponible sur demande

Forme:

Cylindrique

Efficacité d'isolement:

Jusqu'à 95%

Mettre en évidence:

Customizable Friction Damping Vibration Isolator

Cylindrical Spring Isolator

Mounting Installation Vibration Isolator

Conditions de paiement et d'expédition

Quantité de commande min

Conditions de paiement

L / C, D / A, D / P, T / T, Western Union, Moneygram

Produits connexes

JMZ-TK1-50A Helical Structure Spring Steel Friction Damping Vibration Isolator with Vertical Mounting Orientation

Obtenez le meilleur prix

JMZ-TK1-40A Customizable Cylindrical Friction Damping Vibration Isolator with Mounting Installation for Energy & Mining

Obtenez le meilleur prix

JMZ-TK-8A Customized Solutions Stainless Steel Spring Isolator with Excellent Shock Absorption and Easy Installation

Obtenez le meilleur prix

JMZ-TK-7A Corrosion Resistant Friction Damping Isolator with Up to 95% Isolation Efficiency for Vibration Isolation in Energy & Mining

Obtenez le meilleur prix

Nous contacter

86-29-88292913

Contactez-nous maintenant

Description du produit

JMZ-TK1-40A Friction Damping Vibration Isolators

The Ultimate Solution for Vibration Control in High-Precision Equipment

JMZ-TK Series

Guarding the "Precise Hearts" of "Made in China": The Application of JMZ-TK in High-End Industrial Machine Tools

High-end CNC (Computer Numerical Control) machine tools, known as "industrial machine tools," are the cornerstone of the manufacturing industry. Their machining precision directly determines product quality, and vibration is the primary factor affecting this precision. The JMZ-TK series friction damping vibration isolators from Xi'an Hoan Microwave provide outstanding performance for maintaining stable operation of these precision systems.

Dual Protection Against Vibration

In machine tool applications, vibration originates from two main sources:

External Isolation: Effectively blocks transmission of environmental vibrations through the foundation, creating a static reference platform for machining processes.
Internal Energy Dissipation: High damping characteristics quickly attenuate internal vibrations from spindle rotation and cutting operations, improving surface finish and extending tool life.

Performance Benefits

The JMZ-TK series enables micron-level precision in critical applications including:

Aerospace titanium alloy components
Medical device precision implants
Optical lens molds

Structural Dimensions

Installation Dimensions (mm)
Model	B	M	d	A	C	∅1	∅2	H1	H2
JMZ-TK-2.5A～8A	46	6	4.1	58	20	55	22	36	3.6
JMZ-TK1-25A/40A/50A	63	12	8.2	78	20	70	22	56	6

Technical Parameters

Model	Nominal Load (N)	Load Range (N)	Natural Frequency fn≤(Hz)	Loading Working Height H0±1(mm)	Limit Displacement	Maximum Vibration Transmissibility ηv≤	Impact Resistance Test	Service Life (year)
JMZ-TK-2.5A	25	20～30	33	42	4	3	100g	10
JMZ-TK-4A	40	30～50	20	70	7	3	60g	10
JMZ-TK1-25A	250	200～300
JMZ-TK1-40A	400	300～480
JMZ-TK1-50A	500	400～600
